Miller VR500 Fall Arrester for GlideLoc System
The latest generation of guided-type fall arresters provides greater safety and more comfortable climbing from improved design.
Обзор продукта
Highest safety
Unmatched comfort
Robust and durable
Universal applicable
Safety standards
- Quick arrest by allowing the catch nose to fully engage with mounting holes
- For inspection before use: there is a visual fall indicator to reveal whether the shock absorber has been deployed
- Locking pin prevents inserting the shuttle in the wrong direction
Unmatched comfort
- Optimized performance for smooth and uninterrupted sliding performance on all Miller GlideLoc systems
- Ergonomic: Compact and lightweight design for ease of handling.
- Big and 'easy-to-grip' carabiner for ease of opening and closing when wearing gloves
- Carabiner with swivel connection to allow freedom of movement and rotation in all directions
Robust and durable
- Long lifetime with stainless steel shock absorber and internal parts together with high performance polymer wheels
- Housing fully covers the shock absorber to protect against accidental impact: extending the life of the fall arrester and reducing the need for maintenance
- Tri-lock carabiner to withstand up to 6744 lbs with the gate up to 3600 lbs
Universal applicable
- Certified for workers weighing 88 lbs to 310 lbs
- Works with forward and sideway inclined ladders and rails at angles up to 15°
- Tested for rails operating at temperatures ranging from -40°F to 122°F
Safety standards
- Certified according to OSHA 1910.29: ANSI 14.3 – 2008 and EN 353-1:2014+A1:2017
Xарактеристики
Others
- Product Family
- Miller GlideLoc
- Product Thickness
- 2.5 inch
- Standards
- OSHA 1910.29, ANSI 14.3 – 2008 and EN 353-1:2014+A1:2017
- Product Length
- 4.3 inch
- Product Weight
- 1.87 US Pound
Others
- Product Family
- Miller GlideLoc
- Product Thickness
- 2.5 inch
- Standards
- OSHA 1910.29, ANSI 14.3 – 2008 and EN 353-1:2014+A1:2017
- Product Length
- 4.3 inch
- Product Weight
- 1.87 US Pound
- Product Family : Miller GlideLoc
- Product Thickness : 2.5 inch
- Standards : OSHA 1910.29, ANSI 14.3 – 2008 and EN 353-1:2014+A1:2017
- Product Length : 4.3 inch
- Product Weight : 1.87 US Pound
