Subminiature Basic Switches

ZD Series

Up to 3 A ac & dc (UL, cUL, ENEC, CQC). Variety of actuators, forces, terminations. Mounting includes 9,5 mm centers & integral pins

Honeywell’s MICRO SWITCH ZD Series is a sealed subminiature snap action switch. Although small in size, the ZD Series is rated for controlling electrical loads ranging from logic-level (low current, low voltage) to limited power-duty switching (up to 3 A/125 Vac).

The switch when provided with integral wire leads is sealed to IP67 and is suitable for applications where the switch assembly would be exposed to liquids or particulate contaminates in the environment.

Ficha Técnica
Nome
Descrição
Tamanho do arquivo
Data
Tamanho
MICRO SWITCH ZD Series Sealed Subminiature Basic Switches
application/pdf 612.46 KB
8/17/2022
612.46 KB
