Transducteurs de couple de télémétrie analogique (WDC)

Model 1605A

Model 1605A Clamp-on Horsepower Monitoring System. Shaft Sizes From 381 mm to 762 mm [15 in to 30 in]

The Model 1605A universal power and torque measurement system consists of bolt-on shaft sensor units for shafts between 381 mm and 762 mm [15 in and 30 in], which can handle most diesel and turbine power plants. Most ranges of RPM and power are accommodated with large over range capability. The data band width is dc to 1000 Hz, allowing for torsional vibration measurement without a second monitoring system.

Features
  • Enhanced stability
  • Shaft sizes from 381 mm to 762 mm [15 in to 30 in]
  • Uses the components 2100 system to gauge customer shaft assembly with the outputs of a 1602 receiver to measure torque and RPM
